Which Infill Pattern Survives Outdoor UV and Impact Best?
Which Infill Pattern Survives Outdoor UV and Impact Best?
After six months of continuous outdoor exposure, one infill pattern clearly beat the rest: gyroid, with honeycomb trailing close behind, while plain grid and line patterns fell apart fastest. And this wasn’t a cosmetic difference. The winning patterns held onto more than 90% of their impact resistance; the worst performers lost nearly half of theirs. If you’re printing garden fixtures, brackets, drone frames, or car accessories with properly dried PETG, your infill geometry matters almost as much as which filament you loaded.
Why Infill Pattern Matters Outdoors
Infill isn’t just internal “filler.” It’s the load-bearing skeleton of a print. Outdoors, that skeleton gets hit from two directions at once:
- UV radiation breaks down polymer chains at the surface, and the damage travels fastest along thin, unsupported walls.
- Impact loads (hail, drops, knocks, thermal expansion) pile up stress right where infill walls meet the outer shell.
A pattern that keeps walls in continuous, multi-directional contact spreads both attacks out evenly. A pattern made of long, straight, isolated lines does the opposite, it funnels the damage. That’s the real reason geometry, not just density, decides whether a part survives outdoors.
Test Setup and Methodology
We printed 24 test coupons (50 × 50 × 10 mm) across four materials and four infill patterns, all at 30% density.
Materials Tested
- PLA (baseline, weak against UV and heat)
- PETG (the usual outdoor upgrade)
- ASA (built for UV resistance)
- ABS (tough, but UV-sensitive)
Infill Patterns Tested
- Gyroid — continuous sinusoidal walls, no straight load paths
- Honeycomb — hexagonal cells, excellent in-plane stiffness
- Grid — perpendicular straight walls
- Lines (rectilinear) — parallel walls, alternating per layer
Exposure and Measurement
Coupons sat on a south-facing rack tilted at 35° (the same angle used in accelerated weathering standards), taking the full brunt of sun, rain, and temperature swings from -5°C to 38°C. Every 30 days we measured:
- Color shift (ΔE) with a spectrophotometer
- Weight and dimensional change
- Izod impact strength (unnotched) on fresh and exposed samples
Results by Infill Pattern
What surprised us: the rankings held steady across every single material.
- Gyroid, best overall. Held onto 91–94% of impact strength across all four materials. The continuous curves push stress in three dimensions and never give a crack a long, uninterrupted path to follow. UV damage also stayed shallow, since the curved walls expose less flat surface per unit of volume.
- Honeycomb, a strong runner-up. Retained 85–90% impact strength. The hex cells resist in-plane crushing nicely, but their straight cell walls still gave cracks a bit more of a straight-line path than gyroid did.
- Grid, mediocre. Retained just 68–75%. Cracks formed right at the perpendicular intersections, exactly where stress concentrates and UV-thinned plastic fails first.
- Lines, the worst by far. Retained only 52–60%. Since the walls run parallel, a single impact or UV micro-crack could travel the full length of a wall before anything stopped it.
Material × Pattern Interaction
Gyroid boosted every material we tried, but the standout combo was ASA + gyroid: 96% impact strength retained and barely any color shift (ΔE of just 1.8). Even PLA + gyroid outlasted PETG + lines, which tells you something interesting, geometry can partially make up for a weaker filament.
Which Pattern Won and Why
Gyroid pulled ahead for three mechanical reasons:
- No continuous flat plane for a crack to run along
- Self-supporting curved geometry that spreads impact energy outward in all directions
- Better surface-to-volume efficiency, meaning less wall length exposed per unit of strength
There is one trade-off worth mentioning: gyroid prints roughly 10–15% slower than grid or lines, and it puts a bit more load on the slicer. For most outdoor parts, though, that’s a small price for a big jump in durability.
Practical Recommendations
- Default to gyroid for anything that’s going to live outside.
- Pair gyroid with ASA or PETG if you want the best combined UV and impact survival.
- Skip grid and lines for anything load-bearing or weather-exposed.
- Stick to 25–35% density. Past that point, material choice matters more than cranking up infill.
- Add more perimeter walls (3–4) instead of piling on infill, since the shell carries most of the bending and impact stress anyway.
Conclusion
Six months in the field gave us a pretty clear answer: gyroid is the infill pattern that survives outdoor UV and impact best, holding over 90% of its strength while grid and line patterns lost up to half of theirs. If your prints have to deal with sun, rain, or the occasional drop off a shelf, switch to gyroid and pair it with a UV-tolerant material. Your parts will look better, and they’ll simply last a lot longer.
